DAN'S SMALL PARTS AND KITS

BOX 3634

MISSOULA, MONTANA. 59806-3634

PHONE 406 258 2782

---

NOTICE:This is Dan's Internet Catalog No. 8 and all other on-line Catalogs are no

longer valid. Please make sure that you are ordering from this Cat. INTERNET

CATLOG NO. 8 This on line Catalog will be updated often.

---

CHECK OUT DAN'S NEW SPECIAL DEALS NO 2

CLICK HERE

LOTS OF GREAT DEALS..SO TAKE A MOMENT AND VISIT THERE

---

**********NOTICE********** THE UNITED STATED POSTAL SERVICE WILL RAISE THEIR RATES EVERY YEAR IN MAY. DAN'S INCREASED SHIPPING TO USA ZIP CODES A SMALL AMOUNT JULY 19TH, 2008.. THIS IS THE 1ST INCREASE IN SHIPPING FROM DAN'S IN ABOUT 3 YEARS..THE POSTAL SERVICE ALONG WITH ALL THE OTHER SHIPPING SERVICES HAVE RAISED THEIR RATES AT LEAST 3 TIMES OR MORE IN THE LAST 3 YEARS. THE POSTAL SERVICE WILL RAISE THEIR INSURANCE RATES EVERY YEAR ALSO IN MAY. DAN'S WILL NOT ASSUME OR BE RESPONSBILE FOR ANY PACKAGE NOT INSURED....DAN'S RECOMENDS YOU INSURE YOUR PACKAGE.. NOTICE POSTED JULY 19TH,2008

---

CHECK OUT DAN'S NEW CLOSE OUT AND SPECIAL DEALS SITE.

CLICK HERE

---

PLEASE READ BELOW HOW TO ORDER..DAN'S DOES NOT TAKE CREDIT CARDS...ALSO DAN'S DOES NOT TAKE ORDERS OVER THE PHONE...

---

---

DONT'T MISS DAN'S CLOSE OUT SECTION AT BOTTOM OF PAGE .... LOTS OF GOOD ITEMS THAT WHEN SOLD OUT WILL NEVER RETURN CHECK IT OUT!

---

---

HOW TO ORDER..

Use what ever handy for a order form and a copy will be returned with your order.

CLICK HERE FOR ORDER BLANK

Please make sure that payment along with the CORRECT SHIPPING is included with order and send your order to

DAN'S SMALL PARTS AND KITS

BOX 3634

MISSOULA, MT. 59806

Please include your phone no. on your order and this is mandatory for all international orders, there have been some recent changes in custom policy regarding this and if you do not include your phone no. with your order, Dan's will not be able to process..

---

SHIPPING AND HANDLING

Shipping charges for USA AND Possesions WILL BE $6.75 UP TO $75.00..

AND OVER $75.00 ADD $10.00 FOR SHIPPING

NOTE: SHIPPING DOES NOT INCLUDE INSURANCE..WANT YOUR PACKAGE INSURED...USE THE TABLE BELOW FOR COST..

Please make sure you include the correct amount for shipping,if your order does not include the correct amount for shipping..Dan's will not be abel to process your order, and your order will be returned...

INSURANCE RATES EFFECTIVE AUG 1ST, 2008

INSURANCE COSTS BELOW

• $0.01 TO $50.00...$1.70
• $50.01 TO $100.00...$2.15
• $100.01 TO $200.00...$2.2.60
• $200.01 TO $300.00...$4.60
• $300.01 TO $400.00...$5.55

FOR ORDERS MORE THAN $400.00 GO TO THE USA POSTAL WEB SITE AND GET THE COST THERE..

If you choose not to insure your package then you assume all risks to loss and damage and so forth...Dan's Small Parts and Kits will not assume responsiblity for uninsured packages....

*****WANT FREE SHIPPING?***** READ HOW BELOW *** THE FREE SHIPPING OFFER DOES NOT INCLUDE INSURANCE IF YOU WANT TO INSURE YOUR ORDER SEE THE INSURANCE INFORMATION ABOVE FOR THE COST. *** ON ALL ORDERS $75.00 OR GREATER AND THAT ARE PAID FOR WITH A USA POSTAL MONEY ORDER ONLY!!!! PLEASE MAKE SURE YOU UNDERSTAND THIS OFFER..AND OFFER IS FOR CUSTORMERS IN THE USA ONLY. NOTICE: Orders less than $75.00 or orders paid with other than USA Postal Money order..do not qualify for the free shipping offer above. If shipping is not included in orders that do not qualify for the free shipping deal.....Your order will not be processed and will be returned.

Shipping charges to Canada

are $16.50 and due to the high cost of insurance Dan's does not offer this service..Please be advised that you assume all risks and have been notifed here within and are aware of this before you place your order..Dan's will obtain proof of mailing from the Postal Service at time of mailing and will keep this on file for up to one year...(what this means is this will verify that Dan's did mail your order to you to the correct address supplied with your order)

All other international orders

Shipping charge will be $20.00 and due to the high cost of insurance Dan's does not offer this service..Please be advised that you assume all risks and have been notifed here within and are aware of this before you place your order..Dan's will obtain proof of mailing from the Postal Service at the time of mailing and will keep this on file for up to one year..(what this means, is this will verify that Dan's did mail your order to you to the correct address supplied with your order)

PAYMENT

Dan's accepts checks and money orders, and cash and prefers USA POSTAL MONEY ORDERS....All other forms of payment subject to clear before order is shipped....If INTERNATIONAL Payment must be in form of international money order, and Western Union money orders fine( MUST BE USA DOLLARS AND DRAWN ON USA BANK ).

CANADIAN postal money order in USA dollars prefered method of payment for orders from Canada. ...DAN'S DOES NOT ACCEPT CREDIT CARDS..NO COD.. NOR DOES DANS CARRY ACCOUNTS..PAYMENT IN FULL MUST ACCOMPANY ALL ORDERS

---

Backorders

Dan's does not back order and a refund for items either not in stock or sold out will be enclosed with your order.

RETURNS

Items may be returned as shipped by Dan's within 30 days of purchase...customer will pay shipping charges on all returns.

Items returned must not have been used..soldered and must be in the same condition they were when shipped..kits must be returned as received and no returns on kits that have been started will be accepted for return by Dan's.

Dan's reserves the right to refuse a return if the above conditions are not adhered too.

OTHER IMPORTANT INFORMATION

TURN-A-ROUND TIME

Dan's has a 1 to 10 day turnaround time from the time order is received by Dan's and in most cases 3 to 4 days...Dan's has found that the USA POSTAL SERVICE is the best choice over all and this is the service Dan's uses to ship all items.Dan's does not ship by UPS OR FED-X OR DSL...

DISCLAIMER

Please be aware that none of the products offered for sale by Dan's Small Parts and Kits, are intended.. nor suitable for use in end products, that are used for medical equipment, life support systems,nuclear facilities,human implantabel devices and so forth...they are sold for the enjoyment of electronic hobbyist,electronic experimenter's and Amateur Radio builders..

NOTE

Price and availablity of items subject to change with out notice..

---

NOW FOR THE FUN STUFF

---

CLICK HERE FOR MORE FUN

---

JUNCTION FIELD-EFFECT TRANSISTORS:

• 2N5951 N-CHANNEL J-FETS..3/$1.00

• 10 PACK OF 2N5951'S ... $2.50




---



• MPF-102..PRICE 3/$1.25


• 10 PACK OF THE MPF-102'S ... $2.50


  ---

• 2N5486..PRICE 3/$1.25

  10 PACK OF THE 2N5486'S ... $2.50




---




• 2N3819..PRICE 3/$1.25

  10 PACK OF THE 2N5486'S ... $2.50




---



• 2N5457..PRICE ... 3/$1.25

---

J-305.. TO-92 PACKAGE

SAME PINOUT AS THE 2N5486,MPF102, ETC. FETS.

THIS J-FET IS COMPARABLE IN PERFORMANCE TO A 2N4416A AND A 2N5486

AND BETTER THAN A MPF102

IT FEATURES A COMMON SOURCE POWER GAIN OF 11 AT 400MHZ

20 AT 200MHZ, A NOISE FIG. 3.8DB AT 400MHZ AND 1.7DB AT 100MHZ...PRICE 3/$1.50

---

• J-309..PRICE ... 3/1.50




---

• J-310...PRICE 3/$1.50







  ---




• 2N4416A TO-18 4 PIN METAL CAN PRICE ... $1.95 EA.



---



• 2N5485...PRICE ... 3/$1.25




---



• PN4416 J-FET..PRICE ... 3/$1.25


  ---




• 2N5555..PRICE ... $3/1.25



---



• 2N5459/MPF-105..PRICE ... 3/$1.25

---

DUAL GATE MOSFETS:

NOTE: THE DUAL GATE MOSEFTS OFFERED BELOW ARE NO LONGER MADE.

---

---



• BF981 DUAL GATE MOSEFT.

  .7DB NOISE FIG. AT 200 MHZ

  PIN OUT AND DATA HERE


  PRICE...$1.75 EA.


  SPECIAL DEAL.


  5 BF981'S FOR $4.00


  ---




• RCA-3N211 4 PIN METAL CAN TO-18..PRICE...$6.50 EA.



---



• 3N201 4 PIN METAL CAN TO-18..PRICE ... $5.00 EA.



---



• 3N204 ... 4 PIN METAL CAN TO-18 PRICE ... $5.00 EA.



---



• 3N200 ... 4 PIN METAL CAN TO-18 PRICE ... $5.00 EA.



---



• MFE-131 ... 4 PIN METAL CAN TO-18 PRICE ... $5.00 EA.



---



• RCA-40820..4 PIN METAL CAN TO-18 PRICE ... $5.00 EA.


  Special deal on the RCA40820 Dual gates..

  4/$10.00


  Special deals ends August 31, 2009


  ---




• MPF-131 ..PIN OUT SHEET SUPPLIED WITH PART..PRICE..$3.50 EA.



---



• RCA-40822..4 PIN METAL CAN TO-18 PRICE ... $5.00EA.


  GOOD REPLACEMENT FOR RCA-40673


  ---


  HEATSINKS FOR TO-18 AND TO-72 METAL CANS AND ALSO WORK ON TO92 PACKAGE....PRICE...10/$1.50

---

LOW POWER TRANSISTORS

---

---

• 2N2222A TO-18 METAL CAN PRICE ..... 10/$2.50

FAIRCHILD MPSH-81 TO-92 PNP UHF/VHF TRANSISTORS ..... 10/$1.00

FAIRCHILD MPSH-10 TO-92 NPN UHF/VHF TRANSISTORS ..... 10/$1.00

• 2N3906..TO-92..PNP..PRICE ..... 10/$1.00
• 2N3904 TO-92 NPN PRICE ..... 10/$1.00
• PN2907A TO-92 PNP PRICE ..... 10/$1.00
• BC548 LOW NOISE NPN TO-92 PRICE ..... 10/$1.00
• BC257..PNP HIGH GAIN ..... 10/$1.00
• PN2222A'S TO-92 NPN PRICE ..... 10/$1.00
• 2N3565 TO-92 NPN PRICE ..... 10/$1.50
• 2N4401 TO-92 NPN PRICE ..... 10/$1.00


• 2N4403 TO-92 PNP PRICE ..... 10/$1.00
• 2N4126 TO-92 PNP PRICE ... 10/$1.00
• 2N4124 TO-92 NPN PRICE ..... 10/$1.00
• 2N2369 TO-18 METAL CAN NPN .....$3/$1.00
• 2N2219A TO-39 NPN METAL CAN PRICE ..... $3/$1.00
• 2N3053 TO-39 NPN METAL CAN ..... $1.00EA.

• 2N4036 PNP TO-39 METAL CAN PRICE ..... $1.00
• 2N4037 PNP TO-39 METAL CAN .....$1.00 EA.

---

CLICK HERE FOR MORE GREAT TRANSISTOR DEALS

---

RF TRANSISTORS

MRF476/2SC2075 TO-220 PACKAGE ..... PRICE..$3.50 EA.

2SC1253..TO-39 METAL CAN

UHF MICROWAVE NPN BJT

3DB NOISE FIG. AT 200 MHZ

FT 2000MHZ

HFE 20-200

IC (MA) 300

NTE CROSS IS NTE278 (NOTE: 2N5109 NTE CROSS REF. IS SAME NTE278 )THESE ARE NEW OLD STOCK..BY NEC. LONG LEADS AND THEY LOOK LIKE THEY WOULD WORK IN PLACE OF THE MORE EXPENSIVE 2N5109...PRICE ON THE 2SC1253'S ...... $1.50EA..

MRF517 TO-39 METAL CAN .....$2.50 EA.

2N5109..TO-39 METAL CAN..PRICE.....$2.85 EA.

2N3866 T0-39 METAL CAN..PRICE.....$2.85 EA.

2SC2078 TO-220 PACKAGE.....PRICE $3.50 EA.

MRF472 PRICE ..... $3.75 EA.

MOTOROLA MRF8004 TO-39 3.5 WATT AT 27MHZ..PRICE...$3.75 EA.

MRF8004 DATA SHEET HERE


2SC1678 TO-220 PACKAGE PRICE ..... $3.50 EA.

PN918 TO-92 PRICE ..... 10/$1.00

2N2857 TO-18 METAL CAN PRICE .....$1.50 EA.

2N3823 TO-18 METAL CAN PRICE .....$1.00 EA.

PN5179 TO-92 ...PRICE ..... 10/$1.00

2SC1957 PRICE ..... $2.50 EA.




---

2N7000 TO-92 PRICE ..... 3/$1.25


---




MOTOROLA 2N5179 TO-18 METAL CAN PRICE ..... $1.85 Ea.




---




BF181 4 PIN METAL CAN TO-18 4 PINS..LONG LEADS...VHF-UHF NPN AMP, MIXER/OSC TRANSISTORS NICE PARTS PRICE ..... 2/$1.00

2N5770 ..TO-92 PRICE ..... 10/$1.00

2SC799 TO-39 METAL CAN PRICE ..... $3.50 EA.

2N5859 TO-39 METAL CAN PRICE ..... $2.65 EA.

2N918..TO-18 METAL CAN PRICE ..... 2/$1.00

2N5189 TO-39 METAL CAN ..... PRICE 2/$1.00

2N5320 TO-39 METAL CAN PRICE ..... $1.00

2N5321 TO-39 METAL CAN PRICE ..... $1.00

IRF-510 TO-220 PACKAGE PRICE ..... $2.00 EA.

IRF-610 TO-220 PACKAGE PRICE....$1.00 EA.

VN10K TO-92 ..... PRICE $1.00 EA.

---

• 2N3478 TO-72 4 PIN METAL CAN..(SAME PIN OUT AS 2N5179)for VHF/UHF APPLICATIONS

  FEATURES

• Hi gain-bandwidth product-

  ft=900mhz typical

• Low noise figure

  noise fig. 5db typical at 470mhz

  4.5db Max at 200mhz

  2.5db typical at 60mhz

• Hi unneautralized power gain

  gpe = 11.5db at 200mhz

  hermatically sealed 4 lead metal can package

  all active elements insulated from case

  low collector to base feedback capacitance Ccv 0.7pf Max

  GOOD REPLACEMENT FOR THE 2N5179..

  PRICE ..... $.75

HEAT SINKS FOR TO-18 AND TO-72 AND ALSO WORK ON TO-92 PACKAGE...PRICE...10/$1.50

---

LOTS OF SPECIAL DEALS..CLICK HERE

---

VOLTAGE REGULATORS

• 7805 TO-220 PACKAGE PRICE ..... $0.59 EA.
• 7806 TO-220 PACKAGE PRICE ..... $.59 EA.
• 7809 TO-220 PACKAGE PRICE.....$.59 EA.
• 7808 TO-220 PACKAGE PRICE ..... $.59 EA.
• 7812 TO-220 PACKAGE PRICE ..... $.59 EA.

• LM317-T TO-220 PACKAGE PRICE ..... $1.00 EA.


  Summer special on the LM317T'S..

  10/$4.50

  Summer spcial ends AUGUST 31, 2009.

LM337-T TO-220 PACKAGE...PRICE $1.00 EA.

78L24 TO-92 PACKAGE PRICE ..... $.59 EA.

78L18 TO-92 PACKAGE ..... $0.59 EA.

78L15 TO-92 PACKAGE ..... $0.59 EA.

78L12 TO-92 PACKAGE ..... $0.59 EA.

---

78LO9 TO-92 PACKAGE PRICE ..... $.59 EA.

Special deal on the 78L09 100ma Voltage Regulators...20 pieces for only

$3.50

This is a great deal...these are new..long leads and nice to have around

get some while they are available at this great price

Limited time offer.

---

78L08 TO-92 PACKAGE PRICE ..... $.59 EA.

78L06 TO-92 PACKAGE PRICE ..... $.59 EA.

---

78L05 TO-92 PACKAGE PRICE ..... $.59 EA.

---

LM385BZ PRECISION VOLTAGE REG. TO-92 PRICE ..... $1.25 EA.

LM337Z TO-92 PACKAGE NEG. ADJ. VOLTAGE REG. PRICE ..... $1.25 EA.

TL431C PRECISION ADJUSTABLE SHUT VOLTAGE REGULATOR...3 PIN TO-92

PACKAGE..ADJ. FROM 2.5-36 VOLTS PRICE ..... $.59 EA.

Summer special on the TL431'S...

10/$3.75

Summer special ends August 31st, 2009

---

---

LINEAR AND OTHER IC'S

MC1350P 8 PIN DIP PRICE ..... $3.50 EA.

CA3102E 14 PIN DIP PRICE ..... $4.00 EA.

NE602AN 8 PIN DIP PACKAGE PRICE ..... $3.85 EA

SA612AN 8 PIN DIP PACKAGE PRICE ..... $3.85 EA.




LM358 8 PIN DIP PACKAGE PRICE ..... $.79 EA.

CA3046 14 PIN DIP PACKAGE PRICE ..... $1.25 EA.

CA3160 8 PIN DIP PRICE ..... $1.00 EA.

LM386-1 8 PIN DIP PRICE ..... $1.00 EA.

LM386-3 8 PIN DIP PRICE ..... $1.35 EA.

LM380 14 PIN DIP 2 WATT AUDIO AMP PRICE ..... $1.35 EA.

LM380-N 8 PIN DIP PRICE ..... $1.25 EA.

LM1496P 14 PIN DIP PRICE ..... $1.35 EA.

LM-1496H 10 PIN METAL CAN PRICE ..... $4.00 EA.

MC1458 8 PIN DIP PRICE ..... $.65 EA.

TLO-74 14 PIN DIP PRICE ..... $0.89 EA.

TLO-84 QUAD OP AMP 14 PIN PRICE ..... $1.50 EA.

TLO-81 8 PIN DIP PRICE ..... $.79 EA.

TL0-72 8 PIN DIP PRICE ..... $.69 EA.

TLO-82 8 PIN DIP PRICE ..... $.79 EA.

LM324 14 PIN DIP PRICE ..... 3/$1.00

LM301-H 8 PIN CAN PRICE ..... $1.00

NE5532N OR P 8 PIN DIP PRICE ..... $.89 EA.

Summer special on the NE5532N OR P..


5/$3.00

Summer special ends August 31,2009

• NE5534N 8 PIN DIP PRICE ..... $.89 EA.
• NE555 8 PIN DIP PRICE ..... $.59 EA.
• MC1455PI 8 PIN DIP (MOTOROLA IMPROVED VERSION OF THE NE555) PRICE ..... 3/$1.00

---

*****LM4871N AUDIO AMP'S*****

HERE IS A NICE 1.5 WATT AUDIO AMP 8 PIN DIP IC

LOW VOLTAGE...COMPLETE DATA INFO

CLICK HERE

VERY NICE AUDIO AMPS...PRICE...$1.00EA.

OR LIMITED TIME OFFER........5/$3.00

---

SMALL SIGNAL SCHOTTKY DIODES

• BAT85 DO-35 PACKAGE LONG LEADS..PRICE.....10/$3.50
• BAT49 DO-35 PACKAGE LONG LEADS..PRICE.....10/$3.50
• BAT29 DO-35 PACKAGE LONG LEADS PRICE ..... 10/$3.50

• HP-1N5711 DO-35 PACKAGE LONG LEADS PRICE ..... 10/$3.50
• SD103B SCHOTTKY SWITCHING DIODES DO-35 PACKAGE ..... 15/$1.00
• 1N6263 DO-35 PACKAGE LONG LEADS PRICE ..... 10/$3.50

---

---

PIN DIODES

MPN-3404 TO-92 PACKAGE 2 LEADED RADIAL DEVICE PRICE ..... 5/$3.50

---

HYPERABRUPT VARACTOR DIODES.

• BB329 2.2-12.5PF DO-35 PACKAGE LONG LEADS NICE TUNNING DIODES ..... 5/$1.00
• BB409 5-32PF/0-28VDC DO-35 PACKAGE LONG LEADS NICE PRICE ..... 2/$1.00
• MV209 TO-92 PACKAGE PRICE ..... $1.65 EA.

  Summer special..buy 5 of the MV209'S FOR...

  5/$5.00

  Summer speical ends August 31, 2009.




---




• MVAM109 ..... PRICE


  $1.65 EA.


  SPECIAL DEAL ON THE MVAM109'S


  10/$5.00




---




---



• MV1662 PRICE .....

  $1.65 EA.


  SPECIAL DEAL ON THE MV1662'S

  10/$4.50


  ---




• MV2101 ..... $1.35 EA.
• MV2102 ..... PRICE $1.00 EA.
• MV2107 ..... $1.35 EA.
• MV2109 PRICE ..... $2/$1.00

• MV2115 PRICE ..... $2.00 EA.
• MV1644 PRICE ..... $1.00 EA.
• MV2209 PRICE ..... $1.00 EA.
• MV2301 120PF ..... 2/$1.00




• 1S2208 13PF GOOD REPLACEMENT FOR THE MV2103 PRICE ..... 3/$1.00


  SPECIAL DEAL ON THE 1S2208'S


  10/$2.00

• SIEMENS BB104 DUAL 35 PF TUNNING DIODE ( CENTER PIN COMMON ) PRICE ..... 2/$1.00

---

GERAMIUM AND OTHER DIODES

• 1N34 ..... 10/$3.50
• 1N60A ..... 10/$3.50

• 1N82 ..... 10/$3.50
• 1N270 ..... 10/$3.50
• 1N541 ..... 10/$3.50

• 1N914B ..... 35/$1.00
• 1N4004 ..... 25/$1.00
• 1N4007 ..... 25/$1.00
• 1N4148 ..... 50/$1.00

ZENER DIODES

PRICE ON THESE DIODES ARE 6/$1.00 SAME VAULE, NO MIXING.

1N5239/9.1 VOLT *** 1N4752/33 VOLT *** 1N5252/12 VOLT *** 1N5245/15 VOLT

1N5234/6.2 VOLT *** 1N5228 3.9V *** 1N523/4.7 VOLT *** 1N5252/24 VOLT *** 1N4734/5.6 VOLT

1N5231/5.1 VOLT *** 1N5229/4.3 VOLT *** 1N5235/6.8 VOLT *** 1N5236/7.5 VOLT

1N5732B/8.2 VOLT *** 1N4748/22 VOLT *** 1N5241/11 VOLT

CLICK HERE FOR MORE DIODE DEALS

CERAMIC RESONATORS AND FILTERS.

• 455 KHZ CERAMIC RESONATORS $1.00 EA.
• 500 KHZ CERAMIC RESONATORS...SPECIAL DEAL..10/$1.00

• 3.84 MHZ CERAMIC RESONATORS $0.79 EA.
• 8 MHZ CERAMIC RESONATORS..$0.79 EA.
• 4.O MHZ CERAMIC RESONATORS 2 PIN TYPE NO BUILT IN CAPACITOR ..... 10/$1.00




• 4.039 MHZ ..... $0.79 EA.
• MURATA SFE 10.7 MA5-1 CERAMIC FILTER (RED DOT) ..... 10/$1.00

• MURATA SFE 10.7 MA21 CERAMIC FILTER (YELLOW DOT) ..... 10/$1.00
• MURATA 100 MHZ CERAMIC RESONATORS ..... 3/$1.00
• MURATA 10 MHZ CERAMIC RESONATORS ..... 3/$1.00

---

CRYSTALS

• 3.6864 MHZ HC18-U PACKAGE..PRICE $1.00 EA.

• 14.251 MHZ HC18-U PACKAGE ..... $1.00 EA.
• 19.5 MHZ HC18-U PACKAGE ..... $1.00 EA.
• 6.000 MHZ HC18-U PACKAGE ..... $1.00 EA.
• 6.690666 MHZ HC18-U PACKAGE ..... $1.00 EA.
• 14.7456 MHZ HC18-U PACKAGE ..... $1.00 EA.
• 14.251 MHZ HC18-U ..... PRICE $1.00 EA.
• 3.57695 MHZ HC18-U PACKAGE ..... $1.00 EA.

MATCHED CRYSTALS BELOW

• 10 MHZ HC18-U PACKAGE ..... 6/$6.00
• 12.000 MHZ CRYSTALS HC18-U PACKAGE ..... 6/$6.00
• 4.000 MHZ HC18-U PACKAGE ..... 6/$6.00
• 4.032 MHZ HC18-U PACKAGE ..... 6/$6.00
• 9.600 MHZ HC18-U PACKAGE ..... 6/$6.00
• 8.000 MHZ HC18-U PACKAGE .... 6/$6.00
• 8.192 MHZ HC18-U PACKAGE ..... 6/$6.00

---

INA-10386

LOW NOISE, CASCADABLE

SILICON BIPOLAR MMIC AMPLIFIER

FEATURES

• CASCADABLE 50 OHM GAIN BLOCK
• 3DB BANDWIDTH:

  DC TO 1.8 GHZ

• 26DB TYPICAL GAIN AT

  1.5 GHZ

  CLICK HERE FOR DATA SHEET

  THE INA-10386 IS A LOW NOISE SILCON BIPOLOR MONOLITHIC MICRO WAVE INTERGRATED CIRCUIT FEEDBACK AMPLIFIER HOUSED IN A LOW COST SURFACE MOUNT PLASTIC PACKAGE..

  THESE WOULD MAKE A GOOD REPLACEMENT FOR THE MAR-1

  CHECK OUT THE SPEC'S

  THESE ARE PACKAGED IN THE FACTORY TAPE...PRICE ON THESE ARE ..... $2.85 EA.

---

MINI-CIRCUITS PRODUCTS

• MAR-3 ..... $2.65 EA.




• MAR-4 ..... $2.50 EA.

• MAR-6 ..... $2.75 EA.
• ERA-2 ..... $2.25 EA.
• SBL-1.....$7.95 EA.




---




MINI-CIRCUITS ADE-1 SURFACE MOUNT MIXER.








New Minicircuits ADE-1 mixer and includes the little adapter board shown in photo.

By using the little adapter board this makes a lot easier job of using the smt ADE-1 mixer.

The size of the little pc board is 3/4" by 15/16" aprox.

The ADE-1 is the surface mount version of the thru hole SBL-1

The small dot on the ADE-1 is pin 1.

For complete data sheet and infor on the ADE-1


CLICK HERE


Price for the ADE-1 mixer and the board is..

$6.00


Summer special..buy 2 of the little ADE-1'S with boards for..

2/$10.00

Summer special ends August 31st, 2009


Minicircuits current prices for the ADE-1 are as follows.


1-4 Pieces...$14.95 ea.

5-9 Pieces $10.95 ea.

10-24 Pieces $10.45 ea.

25-49 Pieces $2.29 ea.

50-99 Pieces $2.29 ea.

100 pieces...$1.99 ea.


The prices shown above were as of 5-11-2009 and of course they can change them any time so if you want current up to date pricing from them then you will have to go to their web price and check it out.


Note: The ADE-1 mixer is not soldered to the board shown in photo.

Also ADE-1 is not sold separate and neither is the little board.


MORE PHOTOS.








---




UNCL-R1H-2 MIXER ..... $7.00 EA.

MCL PLP-750 LOW PASS FILTER ..... $8.50


PRICE REDUCED TO...$4.50 EA.




MCL T4-1 RF TRANSFORMER .05-200MHZ

THESE ARE NEW AND MINI-CIRCUITS CURRENT PRICE FOR 1 PIECE IS CLOSE TO $5.60EA.

DAN'S SPECIAL PRICE IS ONLY....$3.25 EA.

MCL T1-1T RF TRANSORMER .08-200 MHZ

THESE ARE NEW AND THRU HOLE TYPE.MINI-CIRCUITS PRICE 1-9 PCS IS $4.45EA. DANS PRICE IS $3.50 EA.

---

UPCI651G

Description:

UPC1651G is a silicon monolytic integrated circuit , especially designed as a wide band amplifier ..high frequency through UHF...

• Excellent frequency response: Typical 1200 MHZ
• High power gain: Typical 19db at 500 MHZ
• Low voltage operation, 5 volt

see pic. for pin out infor

PRICE ..... $2.50 EA.

---

TOKO 3 PIN 455 KHZ IF TRANSFORMER SET.

This is a 3 piece set includes 1ST IF YELLOW, 2ND IF WHITE AND 3RD IF BLACK.

The size of these are 10 MM. see cans in pic. below, they are the 3 in a row (top of pic.)

and a pin out sheet is provided with the cans.

PRICE FOR THIS 3 CAN SET IS $2.50

IF TRANSFORMERS:

12.0-20 UH adjustable shielded inductor..

Size is 10MM and (this is the can below the yellow one in the pic above)

These are high quality parts and can be rewound for many different RF projects.

With coil set at 14 uh and a range of capacitors 10-120pf, resonant freq. is 3.8 to 13.5 MHZ. NOTE: with 16 pf these coils cover 10.7 MHZ

Price on these are...$1.00 EA.OR 5 FOR $3.50

The little 12.0-20uh cans are sold out.

---

1 UH 7MM SINGLE WINDING IF CAN.

Nice little cans and middle can, bottom row. (see pic. above)

These have a little knob for adj. or use tunning tool.

PRICE ..... 5/$1.00

---

4 UH 7MM SINGLE WINDING IF CAN.

Nice little cans and middle can. bottom row.(see pic. above)

These have a little knob for adj. or use tunning tool.

PRICE ..... 4/$1.00

---

10:7 MHZ IF CAN. PART NO.IF123 See can, bottom row to right in pic. above.

These are the 10.7 MHZ cans that are used in the Neophyte, NNIG RIG, and other rigs and projects out there.

PRICE ..... $1.65 EA.

10 ASSORTED 455KHZ IF CANS..10MM SIZE..BUY 10 FOR $2.50

---

IC SOCKETS.

---

GREAT DEAL ON 8 PIN PRECISION MACHINED IC SOCKETS..GOLD INNER CONTACTS..CLICK HERE.

---

• 8 PIN IC SOCKETS PRICE ..... 6/$1.00




• 14 PIN IC SOCKETS ..... 6/$1.00
• 16 PIN IC SOCKETS ..... 6/$1.00
• 20 PIN IC SOCKETS ..... 6/$1.00

---

TRANSISTORS SOCKETS:

• TO-3 POWER TRANSISTOR SOCKETS 10 AMP RATING ..... $2.00 EA.

  SHORT TERM SPECIAL ON THE TO-3 SOCKETS...BUY 5 FOR $3.00

SEE GREEN SOCKET IN PIC. ABOVE.

• T0-3 MICA INSULATORS ..... 10/$1.00
• 3 PIN INLINE TRANSISTOR SOCKET

  THIS IS A GOOD SOCKET FOR J-FETS AND LITTLE VOLTAGE REGULATORS

  SEE PIC. BELOW.

  AND OTHER DEVICES WITH 3 IN LINE LEADS

  $3/$1.25

• 3 PIN TRANSISTOR SOCKET FOR TO-92 ..... 3/$1.00




• 4 PIN TRANSISTOR SOCKET FOR TO-18 PACKAGE ..... $2/$1.00>
• 8 PIN ROUND IC SOCKET FOR 8 PIN METAL CAN IC'S ..... 3 FOR $1.00 EA.

SEE PIC. BELOW FOR DESCRIPTION OF SOCKETS ABOVE.

---

CRYSTAL SOCKETS

HC-6 CRYSTAL SOCKET (BLACK SOCKET IN PIC. ABOVE)

PRICE $1.25 EA.

MILLEN HC-6 CERAMIC CRYSTAL SOCKETS

(WHITE SOCKET IN PIC. ABOVE)

..... $2.50 EA.

HC-18U AND HC-49U CRYSTAL SOCKETS.

NO PIC ..... 2/$1.00

---

SINGLE TURN TRIMMER POTENTIOMETERS.

Note: all the trim pots below are priced at 5$1.00 ( not the ones in the pic. below )

No mixing of vaules please..

100 ohm *** 500 ohm *** 1k ohm *** 2k ohm

5k ohm *** 10K *** 20k ohm

25k ohm *** 47k ohm *** 100k ohm

500k ohm *** 1 meg ohm

---

100 ASSORTED TRIM POTS

VAULES LIKE 500 OHM ** 1K ** 2K** 3K** 5K** 10K** 47K** 100k AND MORE...A GREAT WAY TO STOCK UP ON TRIM POTS AND SAVE AT THE SAME TIME...BAG OF 100 PIECES ONLY $5.00

---

MULITURN CERMET TRIMMER POTENTIOMETERS.

3/4" SPECTROL(yellow ones in pic.) 20 turn.

100 ohm $1.00 ea.

5k ohm $1.00 ea.

50k ohm $1.00 ea.

10k 20 turn by Vernitron..(green one in pic.)

Price..$1.00 ea.

MORE MULTITURN TRIM POTS..THESE ARE LIKE ONES IN THE PIC. ABOVE BUT ARE MADE BY MURATA..SIZE..11/16" LONG BY 1/8" WIDE.. VERY NICE 20 TURN TRIM POTS...VAULES AVAIL BELOW...

• 500 OHM..PRICE..2/$1.00
• 1K...PRICE...2/$1.00
• 2K..PRICE...3/$1.00
• 5K..PRICE...$1.00 EA.

1 MEG. AND PRICE..$1.00 EA.

---

POTENTIOMETERS.

• 2K 10 TURN POT.(1ST ONE IN PIC.FROM LEFT TO RIGHT)

  1/4" SHAFT...PRICE...$5.50 EA.

• CLAROSTAT 5K 10 TURN PRECISION POTENTIOMETER

  HAS A 1/2" LONG BY 1/4" SHAFT..BODY IS 40MM LONG. DIA. 26MM

  COLOR GREEN..( NOTE:THESE ARE VERY CLEAN PULLS WITH MANY YEARS OF LIFE LEFT...LIKE NEW )

  PRICE..ON THESE ARE..$8.50 EA..MOUNTING HARDWARE INCLUDED..

• 100K LINEAR POT..NO SWITH...3RD POT IN PIC..( LITTLE ONE )

  1/4" SHAFT INCLUDES HARDWARE...PRICE $1.00EA.

• 10K AUDIO POT WITH SWITCH, 1/4" SHAFT

  LAST POT IN PIC. INCLUDES HARDWARE

  PRICE..$1.65EA.

• 10 K LINEAR TAPER POT..NO SWITH..NO PIC..1/4" SHAFT.

  INCLUDES HARDWARE..PRICE..$1.00 EA.

• 500 OHM AUDIO POT..1/4" SHAFT

  PRICE $1.00 EA. ..HARDWARE INCLUDED

• 1K LINEAR POT..NO SWITCH.

  HARDWARE INCLUDED..PRICE $1.00EA.

• 50K LINEAR TAPER POT WITH SWITCH (ON-OFF)..( NO PIC.) 1/4" SHAFT AND HARDWARE

  INCLUDED....PRICE...$1.00 EA.

---

PRECISION DIALS.

• DUO-DIAL 10 TURN ( 1ST ONE IN PIC. FROM LEFT TO RIGHT )

  PRICE..$6.50..FIT 1/4" SHAFT


  DUO-DIAL..SOLD OUT


• CLAROSTAT 316 SERIES DIGITAL READ OUT DIALS

  15 TURN 2 COLORS..BLACK AND SILVER..

  PLEASE MAKE 1ST THEN 2ND CHOICE

  FIT 1/4" SHAFT AND PRICE IN NEWARKS 1997 CATALOG $21.95..DANS LOW PRICE IS $8.50 EA.

---

SWITCHES

CHECK OUT THE SWITCHES BELOW

Eaton SPDT Toggle Switch

Here are some very nice Toggle switches that are made by Eaton Part no. A121P32Y5CQ.

Made in the USA.

Switch, MINI FLAT HANDLE, SPDT, ON-OFF-ON, 6A@125VAC, 28VDC, 3A@250VAC.

Includes...

Lock washer.

Threaded nut.

Finsh nut with hardware.

These are very nice switches and are expensive at most big parts places....

CLICK HERE TO SEE

Looks like over $15.00 ea.!

You can buy some at Dan's for only...

$1.49ea.

Note:Belive Eaton is part of Electroswitch now.

---

---

REED SWITCH

This reed switch is by Gordus..size is

3/16" dia. aprox by 1 5/8" long.

Heavy 1 amp gold plated contacts.

Price on these nice reed switches is 4/$1.00

Reed switches are sold out.

---

1 POLE 12 POSITION ROTARY SWITCH

HERE IS A VERY NICE 1 POLE 12 POSITION ROTARY SWITCH MADE BY ELECTROSWITCH..(USA)

CLICK HERE FOR SPECS

THESE ARE BRAND NEW SWITCHES

AND KINDA EXPENSIVE AT YOUR FAVORITE PARTS HOUSES

GO TO DANS CLOSE OUTS AND SPECIAL DEALS.

CLICK HERE..ODDS AND ENDS NO.1

FOR PIC. AND PRICE.

---

1 1/2" DIAMETER BLACK FLUTED KNOB

FITS 1/4" SHAFT WITH SET-SCREW

PRICE..$1.25 EA.

1ST KNOB IN PIC. ABOVE..BOTTOM ROW ..TO LEFT.

3/4" DIA. BLACK KNOB FITS 1/4" SHAFT WITH SET SCREW

PRICE..$.59 EA.

MIDDLE KNOB BOTTOM ROW

1 1/8 " DIAMETER KNOB BY DAKA-WARE

FITS 1/4" SHAFT WITH SET SCREW

PRICE..$.79 EA.

DAKA-WARE 1 1/8" KNOB IS SOLD OUT

1 1/8" DIA. BY 7/8" HIGH ROGAN KNOB

BLACK WITH CIRCULAR BRUSHED TOP

BLACK LINE CENTER TO EDGE.

FITS 1/4" SHAFT..INCLUDES SET SCREW

VERY NICE KNOB AND PRICE IS $1.00 EA.


1ST KNOB UPPER ROW IN PIC. ABOVE TO LEFT

11/16" DIA. BY 7/8" HIGH ROGAN KNOB

FITS 3/16" DIA. SHAFT

BLACK WITH CIRCULAR BRUSHED TOP

WITH BLACK LINE CENTER TO EDGE..PRICE..$59 EA.

MIDDLE KNOB IN PIC. ABOVE TOP ROW

3/4 " DIA. BY 3/4" HIGH RAYTHEON KNOB

RAYTHEON PART NO. TSF70..FITS 1/4" SHAFT

INCLUDES SET SCREW AND PRICE $.79 EA.

SMALL KNOB.( NOT IN PIC.)..FOR 1/8" SHAFTS...SIZE OF KNOB IS..1/2" HIGH BY 7/16" DIA...NICE KNOBS...THESE HAVE SET SCREW FOR TIGHT FIT...PRICE..10/$1.00

---

EDGE METERS PANEL MOUNT.

200UA 'S' METER ( 1ST METER IN PIC. ABOVE TO LEFT. )

FACE OF METER IS 1 3/16" BY 1/2" WIDE.

METER READS 0-30DB

YOU CAN REDO IF YOU LIKE

2 MOUNTING TABS FOR MOUNTING.

PRICE ON THIS NICE METER IS $4.50

Edge Meter above is sold out...1st Meter in Photo to the left


---




200 UA 'S' METER SMALL SIZE

FACE OF METER IS 1 7/16" BY 7/16" WIDE.

TOP OF METER FACE IS BLUE AND READS 1-9 + 30 DB

BOTTOM READS 1-5 IN RED NUMBERS.

METER IS MIDDLE ON IN PIC ABOVE

PRICE ON THIS NICE METER IS $4.50 EA.




---




200 UA EDGE METER (LAST METER TO RIGHT IN PIC.)

FACE SIZE IS 1 3/16" LONG BY 1/2" WIDE AND BLUE COVER

SCALE READS ON ONE SIDE 1-30DB

AND OTHER SIDE SAYS POWER 1-25

PRICE ON THIS NICE METER IS $4.50 EA.

---

NOTE..ALL METERS LIMITED QUANITY AND PLEASE MAKE A 1ST CHOICE AND THEN YOUR 2ND CHOICE.

---

SLUG TUNNED COIL FORMS.

• Millen 3/8" DIA. BY 1" LONG CERAMIC COIL FORM

  SLUG TUNNED AND RARE FORM

  PRICE IS..$3.50 EA.

  1ST IN PIC.(LOWER LEFT) ABOVE




---



• MILLEN 1/4" DIA. BY 7/8" LONG CERAMIC COIL FORM

  SLUG TUNNED AND CORE GREEN

  LIMITED QUANITY AND PRICE IS $2.50 EA.

  2ND COIL FORM IN PIC. (LOWER ROW)




---



• MILLEN 1/4" DIA. BY 3/4" LONG CERAMIC COIL FORM

  SLUG-TUNNED..RED CORE..LIMITED QUANITY

  PRICE ON THESE IS $1.75 EA.

  COIL FORM IS 3RD ONE IN PIC. ABOVE (LOWER ROW)




---



• 100UH MILLER SLUG TUNNED PHENOLIC PI-WOUND COIL FORM

  THESE ARE RARE FORMS. SIZE 1/4" DIA. BY 11/16"

  NOTE.SIZE GIVEN IS COIL FORM WINDING AREA ..THE TOTAL LENGHT OF FORM IS 1 1/2" LONG

  4TH ONE IN PIC(BOTTOM ROW)

  PRICE ON THESE RARE FORMS IS $2.50 EA.




---



• LAST COIL FORM ON BOTTOM ROW FAR RIGHT IS

  SLUG TUNNED COIL FORM..30UH AND 60UH..DUAL WINDINGS

  1/4" DIA. AND 2 INCHES LONG..YOU CAN REWIND TO YOUR OWN SPEC'S

  PRICE ON THIS SLUG TUNED COIL FROM IS $1.50 EA.




---



• 1/4" DIA. BY 1 1/2" LONG SLUG TUNNED COIL FORM

  ( 1ST COIL IN TOP ROW IN PHOTO.)

  THE SLUG IN THESE IS 5/8" LONG SO YOU CAN COME UP WITH A NICE RANGE

  EXAMPLE:20 TURNS OF # 20 ENAMEL WIRE = .6UH TO 4.5UH

  32 TURNS OF #24 ENAMEL WIRE =3.2UH TO 4.5UH

  PRICE ON THIS NICE COIL FORM IS..$2.50 EA.


  ---




• 3/16" BY 1" SLUG TUNNED COIL FORM. (2ND IN TOP ROW FROM LEFT TO RIGHT)

  PRICE ON THESE ARE $.50 EA.


  ---







---



• 4TH COIL FORM FROM LEFT TO RIGHT IN PIC.

  33UH SLUG TUNNED COIL FORM 3/16" DIA. BY 1" LONG

  PRICE ON THESE IS $.50 EA.


  ---




• LAST COIL FORM TOP ROW IN PIC.

  47UH SLUG TUNNED COIL FORM 3/16" DIA. BY 1" LONG

  PRICE ON THESE ARE $.50 EA.

---

MINIATURE MOLDED CHOKES

---

NOTE: PRICE ON THESE LITTLE CHOKES LISTED BELOW ARE 3/$1.00..SAME VAULE

---

.22uh ** .39uh ** .47uh ** .56uh ** .68uh ** .82uh ** 1uh ** 1.2uh ** 1.5uh

1.8uh ** 2.2uh ** 2.7uh ** 3.3uh ** 3.9uh ** 4.7uh ** 5.3 uh ** 5.6uh ** ** 8.2uh ** 10uh

12uh ** 15uh ** 18uh ** 22uh ** 27uh ** 33uh ** 39uh ** 47uh ** 56uh ** 62uh ** 68uh

82uh ** 100uh ** 120uh ** 150 uh ** 180uh ** 220uh ** 270uh ** 330uh ** 390uh ** 470uh ** 510uh

560uh ** 680uh ** 820uh ** 1000uh ** 1200uh ** 1500uh ** 3900uh ** 4.000UH ** 4700uh

---

2.5MH PI-WOUND CHOKES PRICED AT $1.50 ea.

---

CORES-FERRTIE BEADS AND WIDE BAND BALUN CORES

---

---

IRON POWDER CORES ( PIC. ABOVE )

---

NOTE: YELLOW CORES ARE # 6 MATERIAL

RED CORES ARE #2 MATERIAL

WHITE CORES ARE #7 MATERIAL

SIZE LISTED BELOW WILL START WITH THE BIGGEST TO THE SMALLEST

FERRITE CORES IN PIC. ABOVE

CORES BELOW AND SEE PIC. FOR SIZE.

• FT114-43 ( BIG CORE IN PIC. )

  PRICE IS $1.25 EA.

• FT50-43 PRICE 3/$1.80
• FT50-61 PRICE 3/ $1.80
• FT37-43 PRICE 3/$1.60
• FT37-61 PRICE 3/1.60
• FT23-43 PRICE 3/$1.00




  SMALLEST ONE IN PIC. ABOVE

FERRITE BEADS AND BALUN CORES IN PIC.

STACKPOLE 2 HOLE BALUN CORE 61 MATERIAL

BIG ONE IN PIC. ABOVE. 1 " LONG BY 1/2" WIDE 1/8" DIA. HOLES

PRICE ON THESE AND LIMITED QUANITY IS $1.25 EA.

BLN43-202 2 HOLE BALUN CORE

2ND ONE IN PIC. ABOVE

PRICE ON THESE IS $1.00 EA.

BLN43-302 2 HOLE BALUN CORE

3RD ONE IN PIC. ABOVE

PRICE ON THESE IS $.69 EA.

BLN43-2402 2 HOLE BALUN CORE

4TH ONE IN PIC. ABOVE

PRICE ON THESE IS $3/$1.00

BLN73-2402 2 HOLE BALUN CORE

4TH ONE IN PIC ABOVE

PRICE ON THESE IS $3/$1.25

FB73-801 BEADS..PRICE DOZ FOR $2.50


FB43-801 FERRITE BEAD

1ST BEAD IN PIC. MIDDLE ROW TO FAR LEFT

PRICE ON THESE IS 12/$2.25

NEXT BEAD ( 2ND ONE MIDDLE ROW ) IS

FB43-302 AND PRICE IS 12/$1.25

FB43-1801 ( 3RD BEAD IN PIC )

PRICE ON THESE ARE 12/$2.25

FB43-202 FERRITE BEAD ( 4TH ONE MIDDLE ROW )

PRICE 12/$1.60

FB43-101 FERRITE BEAD ( 5TH ONE IN MIDDLE ROW )

PRICE 12/$1.50

FAIR-RITE BEAD NO. 2743008111

( LONG BEAD WITH WIRE THRU BEAD BOTTOM ROW )

PRICE 12/$2.00

FAIR-RITE BEAD NO. 2743001111

(SMALLER BEAD WITH WIRE THRU BEAD )

PRICE 12/$1.50

FB73-101 FERRITE BEADS...12 FOR $1.75

FB73-801 FERRITE BEADS...12/$2.75

Ferrite Bead..1/8" Dia. x .037" Thick with 5/32" hole

CORIRON #11-12824, MC25-36BCP.( not in pic. above )

Price..100 pieces for $2.00

50 Assorted Ferrite Beads..lots of sizes..( not in pic. above )

Stock up whille available..Bag of 50 Assorted Ferrite beads..Price..50/$2.50

DANS CAPACITOR SECTION

CERAMIC AND MONOLITHIC CAPACITORS

ALL VAULES LISTED ARE 10 PIECES FOR $0.79( SAME VAULE )

NO MIX OR MATCH..MOST 10% AND SOME 5% AND 50 VOLT

10PF *** 15PF *** 22PF *** 27PF *** 33PF *** 39PF *** 47PF *** 82PF *** 100PF *** 120PF

150PF *** 240PF *** 330PF *** 390PF *** 470PF *** 500PF *** 560PF *** 820PF *** 1000PF *** 1500PF

THE CAPS LISTED BELOW..ARE 10% AND 20% AND A FEW ARE 25 VOLT

SAME PRICE... 10 PIECES FOR $0.79 ( SAME VAULE ) AND NO MIX OR MATCH

.1UF ** .02UF ** .01UF ** .001MF **1500PF ** 2200PF ** 3300PF ** .047UF ** .0047UF ** .005UF ** .05UF

** .022UF ** .22UF

** .005MF 100 VDC 10/$0.79

** .01UF 500 VDC 10/$0.79

200 PIECE BY-PASS CAP KIT

NICE 200 PIECE BY-PASS CAP KIT..ALL 50 VOLT TO 100 VOLT..SMALL SIZE AND NICE TO HAVE AROUND.

50 PIECES EACH OF THE FOLLOWING VAULES IN THIS KIT.

• 50 PIECES .1MF
• 50 PIECES .01MF
• 50 PIECES .001MF
• 50 PIECES .047MF

GREAT DEAL AND PRICE

$5.00

100 ASSORTED TEAR DROP TANTALUM CAPS..SEE PIC. ABOVE FOR WHAT THEY LOOK LIKE..LOTS OF VAULES..AND GET THEM WHILE THEY ARE AVAIL...BAG OF 100 ASSORTED TEAR DROP TANTALUM CAPS FOR ONLY $10.00..

---

TANTALUM ELECTROLYTIC CAPACITORS

TEAR DROP TYPE..RADIAL LEADS

The following vaules are available at this time

minimum voltage is 16 volts..a lot of them are 35 volts

Please make a 1st choice and then a 2nd choice on voltage when you order

35 volt will be sent if available and if not then 16 volt or better will be sent

The Following Vaules Are Available.

• .1uf..Price on these is 4/$1.00

• 1uf..Price on these is 4/$1.00
• 2.2uf..Price on these is 4/$1.00
• 3.3uf..Price on these is 4/$1.00
• 4.7uf..Price on these is 4/$1.00
• 10uf..Price on these is 4/$1.00
• 22uf..Price on these is 4/$1.00
• .33uf..Price on these is 4/$1.00

NOTE: The dipped Tantalums capacitors in the Pic. are a example of what Dipped Tear Drop Tantalums look like.

---

SILVER DIPPED MICA CAPACITORS:

PRICE ON THESE ARE $.40 EA.

---

1PF ** 2PF ** 3PF ** 4PF ** 5PF ** 6PF ** 7PF ** 8PF ** 10PF ** 12PF ** 15PF ** 18PF ** 20PF

22PF ** 27PF ** 30PF ** 33PF ** 36PF ** 39PF * 43PF ** 47PF ** 50PF ** 62PF ** 68PF ** 75PF

82PF ** 91PF ** 100PF ** 110PF ** 120PF ** 125PF ** 130PF ** 180PF ** 200PF ** 220PF ** 240PF

270PF ** 300PF ** 330PF ** 360PF ** 390PF ** 430PF ** 470PF ** 500PF ** 510PF **

620PF ** 680PF ** 750PF ** 820PF ** 910PF ** 1000PF ** 1200PF ** 1500PF **

1800PF ** 2000PF ** 2200PF ** 3000PF ** 3300PF

---

POLYSTYRENE FILM CAPACITORS 5% TOL.50 volt..

10PF ** 56PF ** 100pf ** 110PF ** 120PF ** 150PF ** 180PF ** 220PF ** 270PF ** 330PF ** 390PF ** 470PF

560PF ** 680PF ** 820PF ** 910PF ** 1000PF ** 1200PF ** 1500PF ** 1800PF ** 2000PF

2200PF ** 2700PF ** 3300PF ** 3900PF ** 4700PF

NPO CERAMIC CAPACITORS.5% AND 10%

PRICE ON THESE NPO CAPS 5/$1.00 SAME VAULE, NO MIXING AND VOLTAGE RATING IS 50 VOLTS..

1PF ** 1.5pf ** 1.8pf ** 2PF ** 2.2PF ** 2.7PF ** 3PF ** 3.3PF ** 4pf ** 4.7PF ** 5.1PF ** 5PF ** 5.6pf ** 6PF ** 6.8PF ** 8pf ** 8.2PF

9PF ** 10PF ** 12PF ** 15PF ** 18PF ** 20PF ** 22PF ** 27PF ** 33PF ** 39PF ** 47PF ** 51pf ** 56PF

62PF ** 68PF ** 82PF ** 91pf ** 100PF ** 110PF ** 120PF ** 140pf ** 150PF ** 180PF ** 220PF ** 270PF ** 330PF

390PF ** 470PF ** 560PF ** 680PF ** 820PF ** 1000PF ** 1500PF

• 550 PF 650 VOLT THREADED FEED THRU CAP

  3/8" DIA. AND THREADED AND COMES WITH NUT

  (SEE IN PIC. ABOVE TOP FAR LEFT)

  PRICE ON THESE ARE $1.00 EA.

• 1000PF..650 VOLT..BODY LENGTH 1/2" AND 1/8" DIA. APPROX.

  ( MIDDLE ROW IN PIC. TO THE FAR LEFT )

  PRICE ON THESE NICE FEED THRU CAPS ARE $1.00 EA.

• 1000PF 250 VOLT 1/8 DIA.

  ( 2ND CAP. IN MIDDLE ROW FROM LEFT TO RIGHT )

  PRICE ON THESE NICE FEEDTHRU CAPS ARE 10/$3.50

• 500PF FEED THRU CAP..

  ( 3RD ONE IN PIC. MIDDLE ROW )

  PRICE ON THESE ARE 3/$1.00

• 10PF FEET THRU CAP.

  ( 4TH CAP IN PIC. MIDDLE ROW )

  PRICE ON THESE ARE 3/$1.00

8PF FEED THRU CAP.

( LAST ONE IN PIC. MIDDLE ROW )

PRICE ON THESE ARE 3/$1.00

• 1500PF FEED THRU CAP 1/4 DIA. BY 1/8 DIA.

  ( BOTTOM ROW IN PIC. WITH WIRE THRU CAP )

  RATED AT 350 VOLTS AND PRICE ON THESE ARE 10/$3.50

• 1000 PF FEEDTHRU CAP. SAME AS THE 1500PF FEEDTHRU CAP

  ( SEE CAP. BOTTOM ROW IN PIC. )

  RATED AT 350 VDC AND PRICE ON THESE ARE 10/$3.50

• 3300PF FEED THRU CAP..350 VDC...NO PIC..BUT LIKE THE ONE IN THE BOTTOM ROW OF PIC WITH FACTORY LEADS..

  PRICE ON THESE ARE 10/$3.50

.001MF OR 1NF 400 VOLT FEED TRU CAPS..VERY NICE ITEMS..MADE BY STETTNER ELECTRONICS COMPONENTS...GERMANY..HIGH QUALITY ITEM...SEE PIC. ..PRICE BUY 10 PIECES FOR $3.50

30 PIECE FEED THRU CAPACITOR KIT

HERE IS A NICE 30 PIECE FEED THRU CAP. KIT

KIT INCLUDES 5 EA. OF THE FOLLOWING VAULES

• 27PF 500 VDC
• 100PF 350 VDC
• 470PF 500 VDC
• 1000PF 250 VDC
• 1500PF 350 VDC
• 3300PF 350 VDC

PRICE ON THIS NICE 30 PIECE FEED THRU CAP KIT IS.............. $6.50

MODEL #5670 HEAVY DUTY JACKSON BROS. 6:1 EPICYCLIC DRIVE

1/4" SHAFT AND OUTPUT FITS 1/4" SHAFT

THE SHAFT AND BALL RACES ARE MACHINED AND HARDENED TO PROVIDE OUTPUT TORQUE IN EXCESS OF 100 OZ..

IF YOU HAVE A BIG AIR VAIRABLE YOU WANT TO TURN AND NOT HAVE DRIVE SLIP

THEN THIS IS THE ONE TO USE..

PRICE ON THESE VERY NICE EPICYCLIC DRIVE IS $50.00

THIS WONDERFULL HEAVY DUTY BALL DRIVE IS SOLD OUT

MINIATURE 10:1 REDUCTION DRIVE MODEL #5870

THESE ARE NICE TO HAVE FOR YOUR HW-9 OR FOR LITTLE AIR VAIRABLES AND POTS

SHAFT IS 5/32" AND OUT PUT FITS EITHER 1/4" SHAFT OR 3/16" SHAFT

( PLEASE INDICATE WHEN YOU ORDER , EITHER 1/4" ON THE OUT PUT OR 3/16" ON THE OUTPUT

REDUCTION RATIO ON THESE IS 10:1 AND OUTPUT TORQUE IS 8 OZ.

PRICE ON THESE IS $15.00

Summer special..on the little #5870 ball drives...

$12.50

Summer special ends August 31,2009

NOTE:USE A 1/4" OUTSIDE DIA. SPACER AND DRILL OUT THE CENTER WITH 5/32" DRILL

AND YOU HAVE A ADAPTER THAT YOU CAN USE 1/4" INSIDE DIA. KNOB

IF USING FOR HW9..THE KIT INCLUDED AN ADAPTER

EPICYCLIC CORD DRIVE NO. 4413 AND ALSO INCLUDES PULLY

THESE ARE A NICE 5:1 REDUCTION DRIVE IMPUT TORQUE IS 3 OZ

OUT PUT TORQUE IS 8 OZ, HAS 1/4" SHAFT FOR 1/4" INSIDE DIA. KNOB.

PULLEY IS FOR THE AIR VAIRABLE AND 2 SET SCREWS INCLUDED

PRICE ON THIS DRIVE AND PULLEY IS $10.00

THIS DRIVE IS A 2 SPEED DRIVE AND NOT SURE ON THE MODEL NO. BUT IS J.B.

STANDARD 6:1 REDUCTION OR DIRECT AND 1/4" SHAFT

THE OUTOUT FITS 1/4" SHAFT AND PRICE ON THESE IS $13.50

THIS DRIVE IS A J.B. 7:1 REDUCTION AND HAS 1/4" SHAFT FOR 1/4" INSIDE DIAL KNOB

AND ALSO THE OUT PUT ON DIRVE FITS A 1/4" SHAFT

OUTPUT TOURQUE IS APROX 26 OZ. AND HAS A DIAL PLATE

WITH 2 THREADED HOLES FOR MOUNTING A DIAL

HAS 2 U-SHAPED EARS ON THE FLANGE FOR PANEL MOUNTING

PRICE ON THESE NICE LITTLE DRIVES IS $13.50 EA.

---

THIS IS A JACKSON BROS. 2 SPEED DRIVE NO. 4832/2K

REDUCTION RATIO IS 5 1/2 TO 1 ..OUTPUT TOURQUE IS 8 OZ.

1/4" DIA. IMPUT AND 1/4" DIA. OUT PUT..PRICE IS $12.50 EA.

---

UNIVERSAL COUPLING NO. 5610

SEE IN PIC. ABOVE TO THE LEFT

BREAK DOWN VOLTAGE IS 3KV AND 1/4" DIA. HOLES

TO FIT 1/4" SHAFT..VERY NICE PART AND PRICE ON THESE IS $5.00 EA.

INSULATED EXTENSION SPINDLE 3KV RATING

SEE IN PIC. ABOVE TO THE RIGHT

1/4" SHAFT FOR 1/4" INSIDE DIA. KNOB AND THE OUT PUT IS 1/4" DIA.

PRICE ON THESE NICE LITTLE INSULATTED EXTENSION SPINDLES IS $5.00 EA.

---

THESE ARE LITTLE PANEL MOUNT BEARINGS AND 1/4" BORE

USE THESE ON PANEL FOR SMOOTH SHAFT ROTATION WITH NO RUBBING OR HANG UPS

PRICE ON THESE ARE $1.65 EA.

---

• 2 PIECE GLAZED CERAMIC FEED THRU INSULATOR

  MADE BY HERMAN H. SMITH AND CO. SIZE IS 1 AND 1/4" LONG

  AND INCLUDES ALL THE HARDWARE AND PRICE ON THESE IS $3.95 EA.

---

CLICK HERE FOR

MORE BNC CONNECTORS AND STUFF

---

• 6 FEET OF RG-174U COAX CABLE THIS IS NICE CABLE

  THERE IS A LITTLE RF CONNECTOR ON ONE END..

  IF NOT WANTED OR NEEDED JUST CLIP OFF

  PRICE IS $1.00 EA.


---

---

MAGNET WIRE

25 FOOT PIECES OF MAGNET WIRE IN THE FOLLOWING GAUGES..

• NO 22 15 FEET FOR $1.00
• NO. 24 25 FEET FOR $1.00
• NO. 26 25 FEET FOR $1.00
• NO. 28 25 FEET FOR $1.00
• NO. 30 25 FEET FOR $1.00
• NO. 31 25 FEET FOR $1.00
• NO. 32 25 FEET FOR $1.00
• NO. 36 25 FEET FOR $1.00

• UNGAR PL340 MICRO SPADE 1/8" THREAD IN SOLDER TIPS

  THESE ARE IRON CLAD AND FIT. RADIO SHACK PENCIL IRONS

  UNGAR 4034..1235 AND 535 AND OTHERS

  NOTE:MOUSER SELLS A ADAPTER THAT FITS 1/4"

  THREADED HEATING ELEMENTS AND THIS ADAPTER ADAPTS TO THE 1/8' UNGAR PL340 THREADED TIPS

  THESE TIPS ARE AROUND $3.96 IN MOUSER CAT.

  DAN'S PRICE IS CHEAP....3 FOR $1.00

DAN'S HARDWARE SECTION

SOLDER POSTS...MACHINE SCREWS..PC BOARD DRILL

BITS..PC BOARD SPACER KITS...

---

GOLD TEFLON SOLDER POSTS.

100 GOLD TEFLON SOLDER POSTS

Posts are 11mm long and press fit from the bottom of the board through a 1/8" hole

The gold turrent is gold plated and price is...100 for $10.00

PRICE FOR 50 PIECES OF THE GOLD TEFLON SOLDER POSTS IS 50/$5.00

SET SCREWS

• 8-32 X 1/2" Set Screws 6-32 Thread..Price 20/$1.00

MACHINE SCREWS.

• 6" X 6" Double Sided PC Board...$2.25 EA.
• 5" X 7" Double Sided PC Board...Price $2.25 EA.

5 PIECE SINGLE SIDED PC BOARD KIT

• 1 Piece 2" X 4"
• 1 Piece 2" X 3"
• 1 Piece 1 1/2" X 4"
• 1 1/2" X 3"
• 1 3/4" X 2"

Price on this 5 piece single sided pc board kit...$2.25

---

7 PIECE DOUBLE SIDED PC BOARD KIT

• 1 Piece 3" X 3"

• 1 Piece 2" X 4"
• 1 Piece 2" X 3"
• 1 Piece 2" X 2"
• 1 Piece 1 1/2" X 3"
• 1 Piece 1 1/2" X 2"
• 1 Piece 1" X 2"

Price on this 7 Piece double sided pc board kit..$2.50

15 Piece Motorola Hot Carrier Diode Kit.

Kit Contains 5 EA. of The Following

MBD-101 *** MBD-102 *** MBD-301

Price For This 15 Pieces Kit..$4.50

25 PIECE NPO CAPACITOR KIT

KIT CONTAINS 5 EA. OF THE FOLLOWING VAULES

TIGHT TOL. +-.25% 100 VOLT

5 EA. OF THE FOLLOWING.

• 1.8PF
• 2.7PF
• 3.3PF
• 6.8PF
• 8.2PF

PRICE ON THIS 25 PIECE NPO KIT...$3.00

---

CERAMIC FILTERS AND RESONATOR GRAB BAG.

If you like ceramic filters and resonators then this

deal is for you..Lots of different types here

Bag of 100 assorted ceramic filters and resonators..PRICE..$5.00

THIS IS A NICE ASSORTMENT OF ALL DIFFERENT KINDS OF INDUCTORS, MOLDED,AND COIL FORMS AND IF CANS...

THERE ARE SLUG TUNNED AND ALSO SLUG TUNNED IF CANS

LOTS OF DIFFERENT VAULES AND A GREAT DEAL FROM DAN'S...PRICE WHILE THEY LAST...IS BAG OF 100 FOR .....$5.00

Summer special..buy 2 of the 100 piece assorted inductors and if cans for..

2/$8.00

Summer special ends August 31, 2009

500 PIECE GRAB BAGS.

500 Piece grab bags are back.

These have a little of this and a little of that in them.

like crystals, caps, resistors,inductors and other odds and ends, and have always sold out in the past.

Price on the 500 Piece grab bags $5.00

Special deal..buy 2 of the 500 piece grab bags for only...

$8.00

NOTE: Bcause of weight the 500 piece grab bags are available to USA BUYERS ONLY.

100 ASSORTED TANTALUM CAPACITORS

This is a great way to stock up on these nice capacitors.

100 piece Tantalum assortment..lots of vaules..PRICE..100 for $6.00

---

---

20 PIECE SIEMENS VARACTOR TUNNING DIODE KIT.

5 EA. OF THE FOLLOWING VAULES

• 5 BB104 DUAL 35PF
• 5 EA.BB605 33.5PF
• 10 EA. BB329 12.5 PF

PRICE FOR THIS 20 PIECE KIT....$4.50

---

---

30 PIECE TANTALUM CAPACITOR KIT

RATED AT 15 VOLTS OR BETTER

CONTAINS 5 EA. OF THE FOLLOWING VAULES

• .47UF
• 1UF
• 2.2UF
• 10UF
• 22UF
• 33UF

PRICE ON THIS NICE 30 PIECE TANTALUM KIT..$3.00

---

---

---

DAN'S DOLLAR DEALS

THIS SECTION HAS A LOT OF GOOD DEALS AND EACH

DEAL IS ONLY $1.00 PER BAG.

---

• 20 PIECE NPO KIT..10 PIECES 100PF NPO AND 10 PIECES 47PF NPO..20 PIECES TOTAL..PRICE IS..$1.00


  Summer special on the 20 piece npo kit...


  5 kits for..$3.00

• 16UH AXIAL INDUCTORS..NICE PARTS..PRICE..6/$1.00
• JW MILLER 10UH 1.5 AMP AXIAL INDUCTORS...PRICE 10/$1.00
• 10UH 500 MA. RADIAL INDUCTORS..10/$1.00
• THERMISTORS.RADIAL LEADS...ROOM TEMPERATURE APRON 80 DEG.

  FAHRENHEIT 510 OHMS

  APPROXIMATE.IN BETWEEN TWO FINGERS RESISTANCE DROPS TO 393

  APPROXIMATE..WE HAVE NO IDEA WHAT THESE ARE GOOD FOR..BUT A LOT OF

  YOU HAVE BOUGHT THEM IN THE PAST..PRICE..10 PIECES FOR ONLY $1.00

• 50K THERMISTORS..THIS IS THE RESISTANCE AT ROOM TEMP APROX. AND THESE

  ARE NEG. TEMP. TYPE..THERMISTORS..RADIAL LEADS...GRAB SOME AT A GREAT

  BUY AT 10 PIECES FOR $1.00

• 1N5406. 3 AMP 600 VOLT RECTIFIER DIODES..LONG LEADS..10/$1.00

  100/$6.50

  Summer special ends August 31st, 2009

• 180PF DIP MICA 1% TOL. 500 VOLT 5/$1.00
• 1300 PF DIP MICA 5% 500 VOLT

  RADIAL STYLE..PRICE OF THESE DIP MICA. CAPS..4/$1.00

• 625PF 5% TOL. 500 VOLT DIP MICA CAPS

  RADIAL STYLE..PRICE ON THESE WILL BE 4 FOR $1.00

---

KITS

---

LITTLE JOE TRANSMITTER KIT

From QRP Classics page 9 amd also featured in Solid State Design

Kit includes nice little etched circuit board and all board mount components.

NOTE: KIT DOES NOT INCLUDE CRYSTAL

AVAILABLE for the following bands and make sure you indicate the band you want, when you order

• 160 METERS
• 80 METERS
• 40 METERS
• 20 METERS
• 10/15 METERS

PRICE ON THIS NICE LITTLE TRANSMITER KIT IS $19.95

---

IMPROVED NEOPHYTE RECEIVER

This receiver was featured in the spring 1994 issue of Ham Brew Magazine

Designed by Wes Baden, K6EIL

This is a nice 40 meter receiver and uses a NE602AN OR NE612AN mixer chip

and incorporating an AF pre-amplifier and bandpass audio filter

will drive a 2 1/2" to 3" speaker to room level volume.

Kit includes etched circuit board and all board mount components

included is a very nice 20pf air vairable capactior..double bearing type

has built in 8:1 reduction and 1/4" shaft

copy if artical included with kit...price of this kit is...$32.95

---

THE TRAVELER 80 METER SSB/CW RECEIVER KIT

This is a very nice 80 meter ssb/cw home-brew receiver

designed by Paul G Daulton..featured in Oct. 1994 issue of 73 Amateur Radio Today

This is a simple, hi-performance, 80 Meter SSB/CW receiver

designed around the Motorola MC3335P IC CHIP. The receiver is a

true single-sideband superhetrodyne, with a 3 crystal filter

and also a crystal controlled vfo..very nice receiver kit

Kit includes a nice silk screened etched circuit board

and all board mounted components and also the vol. pot and the 10 turn tunning pot.

both pots have 1/4" shafts and fit 1/4" inside dia. knobs>

Price on this very nice receiver kit is $39.95

THE TRAVLER KITS NOW USE THE MC3362P CHIP

---

ANTENNA TUNER KITS

QRP MINI-TUNER RATED AT 10 WATTS MAX.

This is a compact QRP Antenna Tuner featured in the October issue of 73 Magazine.

Artical by Mark L.Meyer

This kit contains two 200pf air variables with 1/4" shaft

2 bnc connectors..toroids..wire..and instructions

also includes 1 pole 12 position switch 1/4" shaft

Price on this nice little tunner kit is...$15.00..

20 TO 25 WATT VERSION OF THE QRP TUNNER...PRICE..$29.95

THIS TUNNER IS ALSO GOOD FOR SHORTWAVE RECEIVERS

COVERAGE FROM 3.5MHZ TO 29.5MHZ..

---

QRP DUMMY LOAD..RF SENSOR KIT.

This is a little Dummy load and rf sensor kit that was featuredin the Autumn 1995 Hambrew Magazine

The artical was by Bill Hickox K5BDZ. This dummy load will handel up to 20 watts

The kit comes with a little 1 3/4" by 1/3/4" board and all the parts, includes a 200ua meter..( no case included )

Price on this kit is...$15.00..includes a copy of the artical..

NEW CLOSE OUT PRICE

CLICK HERE

---

SIMPLE SWR METER KIT

This is a little SWR/POWER meter kit that works and does not cost you $60.00 to $100.00

The kit and artical was featured in the spring 1995 HAM BREW MAGAZINE.

Bill Hickox k5bdz was the author of the artical and also the designer

The kit comes with a 1 3/4" by 1 3/4" board and the components for the board and a 200ua meter

Price..is $15.00..

copy of artical included

NEW CLOSE OUT PRICE HERE

CLICK HERE

---

DOUBLE BALANCED MIXER KITS

Roll your own double balanced mixer and save money while having fun and getting experince winding cores.

This kit includes a matched set of hot carrier diodes plus the cores and no. 28 mag. wire

Includes the 1 sheet of instructions and available with the following cores.

• FT37-43 CORES
• FT37-61 CORES
• FT23-43 LITTLE CORES

PLEASE INDICATE WHAT CORES YOU WANT WITH KIT WHEN YOU ORDER

PRICE..will be $2.50 ea.

---

---

SURFACE MOUNT FUN

---

CHECK OUT DAN'S NEW SURFACE MOUNT CLOSE OUTS AND SPECIAL DEALS PAGE.

CLICK HERE

---

NOTE..THIS SECTION WILL CHANGE OFTEN...SO IF YOU

SEE SOMETHING YOU WANT..THEN GET IT NOW...IT MIGHT NOT BE THERE

THE NEXT TIME YOU LOOK...

---

SEMICONDUCTORS

NE602AN SO-8 PACKAGE..SURFACE MOUNT...PRICE FOR THESE IS..$2.85EA.

SA612A SO-8 PACKAGE...SURFACE MOUNT...$2.85 EA.

TLO-72..SO-8 SURFACE MT...3/$1.00

MBBT2222A SOT-23 PACKAGE.....PRICE 12/$1.00

MMBT3904 SOT-23 PACKAGE.....PRICE 12/$1.00

MMBT3906 SOT-23 PACKAGE.....PRICE 12/$1.00

2N7002 N CHANNEL MOSFET SO-23 PACKAGE.....PRICE 12/$1.00

MMBT3640 SO-23 PACKAGE.....PRICE 12/$1.00

3SK177 Dual gate GaAsfet SOT-143 PACKAGE

NICE PARTS..ON TAPE AND REEL ( ANTI-STATIC)

PINOUT WITH PARTS..PRICE 5/$4.50

---

BF998 SILICON N-CHANNEL DUAL-GATE MOSFET

Integrated gate protective diode

Low noise figure

Low feedback capacitance

Low noise figure, 1db @ 200mhz and 1.5db @ 800mhz

Power gain 28db @ 200mhz, 20db @ 800mhz

Case size is SOT-143

SPEC. SHEET WITH PIN OUT INCLUDED...COMES ON FACTORY TAPE AND REEL IN ANTISTATIC PACKAGING

PRICE ON THESE ARE...5/$4.00

---

WJ COMMUNICATIONS, INC

HIGH PERFORMANCE PRODUCTS

FH1.....HIGH DYNAMIC RANGE FET.

PRODUCT FEATURES.

50-3000 MHZ BANDWITH

+42 DBM OUTPUT IP3

1.2DB NOISE FIGURE

18DB GAIN

+21 DBM P1DB

SINGLE OR DUAL SUPPLY OPERATION

MTBF>100 YEARS

SOT-89 SMT PACKAGE

THESE ARE ON FACTORY TAPE AND REEL..VERY NICE PARTS..LIST PRICE IN QUANTIY

OF 1-9 PIECES $5.21 EA.

DANS PRICE IS 4 PICES FOR $10.00

FOR MORE INFORMATION ON THESE NICE PARTS CHECK OUT THEIR WEB SITE.....WWW.wj.com

1 PAGE DATA SHEET WITH PIN OUT SUPPLIED WITH ORDER.

---

wj AH1 HIGH DYNAMIC RANGE AMPLIFIER

PROCUCT FEATURES

250-3000 MHZ

+41 DBM OUTPUT IP3

2.7 DB NOISE FIG.

+21 DBM P1DB

MTBF>100 YEARS

SOT-89 SMT PACKAGE

SINGLE +5 VOLT SUPPLY

THESE ARE ON FACTORY TAPE AND REEL..VERY NICE

PARTS..LIST PRICE IN QUANTIY OF 1-9 PIECES $5.86 EA. AND

DANS PRICE IS 4 PIECES FOR $10.00

FOR MORE INFORMATION ON THESE NICE PARTS CHECK OUT THEIR WEB SITE. WWW.wj.com

1 PAGE DATA SHEET SUPPLIED WITH ORDER

---

TUNNING DIODES

SMV1212...50PF...PRICE 2/$1.75

MV1494 39PF...PRICE 2/$1.75

---

SURFACE MOUNT TRIMMER POTENTIOMETERS

500 OHM 3.75MM X 3.75MM SQUARE

TOP ADJ. CERMENT...PRICE 2/$1.00

47K TOP ADJ. SMT TRIM POTS..SIZE 4.25MM X 4.75MM..PRICE 3/$1.00

BOURNS 1K 5MM X 5MM SQUARE TOP ADJ.

CERMENT/SEALED...PRICE 2/$1.00

BOURNS 10K 5MM X 5MM SQUARE TOP ADJ. CERMENT/SEALED

PRICE ON THESE ARE 10/$3.50

---

240 PIECE SURFACE MOUNT INDUCTOR KIT.

NOTE: The photo above give you a idea of the different case sizes in this nice SMT inductor kit.

Here is a very nice surface mount inductor kit and includes the following vaules.

10 pieces 1uh case size 1210 10% tol. 1RO on case.

10 pieces 1.5uh case size 1210 20% tol. 1RM5 on case.

10 pieces 1.8uh case size 1210 10% tol. 1R8 on case.

10 pieces 2.2uh case size 1210 5% tol. case blank.

10 pieces 2.7uh case size 1210 5% tol. 2.R7 on case.

10 pieces 3.3uh case size 1210 20% tol. 3R3M on case.

10 pieces 4.7uh case size 1210 5% tol. 4R7J on case.

10 pieces 5.6uh case size 1210 5% tol. 5R6J on case.

10 pieces 10uh case 1812 5% tol. 100 on case.

10 pieces 12uh case 1210 5% tol. 120J on case.

10 pieces 15uh case 1812 10% tol. 150 on case.

10 pieces 22uh case 1210 10% tol. 220 on case.

10 pieces 33uh case case 1812 5% tol. 330 on case.

10 pieces 39uh cas3 1210 5% tol. 390J on case.

10 pieces 47uh case size 1812 5% tol. 470 on case.

10 pieces 68uh case size 1812 5% tol. 680J on case.

10 pieces 82uh case size 1812 10% tol. 820k on case.

10 pieces 100uh case size 1210 5% tol. 101J on case.

10 pieces 120uh case size 1210 5% tol. 121J on case.

10 pieces 150uh case size 1210 10% tol. 151 on case.

10 pieces 180uh case size 1812 10% tol. 181K on case.

10 pieces 220uh case size 3/16" sq. 10% tol. 221 on case.

10 pieces 330uh case size 1812 5% tol. 331J on case.

10 pieces 1000uh caze size 1812 5% tol. 102J on case.

Price on this nice 240 piece surface mount inductor kit.

$16.50

SURFACE MOUNT CAPACITORS

300 PIECE HIGH VOLTAGE BY PASS SMT CAP KIT.

Here is a nice high voltage surface mount by pass cap kit.

100 Pieces .luf 500 volt case 1210 +-10% tol.

100 pieces .01uf 500 volt case 1210 +-20% tol.

100 pieces .001uf 1000 volt case 1808 +-10% tol. NPO.

Price on this nice 300 pices high voltage surface mount by pass cap kit is..

$10.00

This is a great deal on this 300 piece high voltage SMT cap by pass kit.

700 PIECE SMT BY-PASS CAP. KIT.

Here is a nice 700 Piece surface mount by pass cap. kit.

7 different vaules and a great deal.

100 pieces each of the vaules listed below and each vaule in its own bag as in photo.

100 Pieces .1uf 100 volt 10% tol. case 1206.

100 Pieces .01uf 100 volt 10% tol. case 1206.

100 Pieces .001uf 100 volt 10% tol. case 1206.

100 Pieces .047uf 50 volt 10% tol. case 1206.

100 Pieces .0047uf 50 volt 5% tol. case 1210.

100 Pieces .22uf 25 volt 10% tol. case 1206.

100 Pieces 1uf 25 volt +80 -10 % tol. case 1210.

If you bought these from one of the major parts houses you would pay well over $75.00 for what you see here.

This is a great assortment for the person that is into surface mount.

Price on this nice 700 Piece by pass cap kit.

$12.50

---

SMALL SURFACE MOUNT ELECTROLYTIC CAPS.

Here are some nice surface mount electrolytic caps.

These were made in Japan and are of good quality.

---

100uf SMT Electrolytic Capacitors.

100 Pieces 100uf 16 volt size 6.3mm X 5.5mm +-20% TOL.

These are very nice 100uf electrolytic caps and priced at..

100/$5.00

47UF SMT Electrolytic Capacitors.

100 Pieces 47uf 16V size 6.3mm X 5.3mm +- 20% tol.

These are very nice 47uf electrolytic caps and priced at...

100/$5.00

22UF SMT Electrolytic capacitors.

100 Pieces 22uf 35 volt size 6.3mm X 5MM -20\+20% tol.

These are very nice 22uf electrolytic caps and priced at...

100/$5.00

10UF SMT Electrolytic capacitors.

100 Pieces 10uf 35 volt size 5.0mm X5.0 mm -20\+20% tol.

These are very nice 10uf electrolytic caps and priced at...

100/$5.00

4.7UF SMT Electrolytic capactiors.

100 Pieces 4.7uf 35 volt size 4mm X 5mm -20\+20% tol.

These are very nice 4.7uf electrolytic caps and priced at...

100/$5.00

100 ASSORTED SMT ELECTROLYTIC CAPS.

100 Assorted surface mount electrolytic caps.

This is a great deal and priced at...

100/$3.50

SURFACE MOUNT BY PASS CAPS.

.1UF ( 104 ) CASE 0805 TOL. X7R 10% 50 WVDC..100 PIECES TAPE AND REEL...$3.00

.01UF ( 103 ) CASE 0805 TOL. X7R 10% 50 WVDC..100 PIECES TAPE AND REEL...$3.00

.01UF ( 103 )CASE 0603 TOL. X7R 10% 50 WVDC..100 PIECES TAPE AND REEL...$3.00

.001UF ( 102 ) CASE 1206 TOL. X7R 10% 50 WVDC..100 PIECES TAPE AND REEL...$3.00

LOTS MORE SURFACE MOUNT CAP DEALS.

CLICK HERE

SURFACE MOUNT TRIMMER CAPACITORS

5PF-30PF SMT TRIMMER CAPACITOR.. TOP ADJ. 3MM x 5MM

COLOR GREEN...PRICE 2/$1.00

2.5-10PF NPO SMT TRIMMER CAPACITOR.. TOP ADJ. 3MM X 5MM..PRICE 3/$1.00

VOLTRONICS 0-3.5PF NPO SMT TRIMMER CAPACITOR .. TOP ADJ. SIZE 3.5MM X 5 MM

PRICE ON THESE IS....5/$1.00

10UF 16 VOLT 10% TOL. TANTALUM CAPACITORS..CASE SIZE D. PRICE 25/$2.50

LM358 SO-8 PACKAGE..PRICE 4/$1.00

ELIPTEK 3.6864 CRYSTAL ( CERAMIC PACKAGE/GOLD LEADS )7.5MM LONG X 5MM WIDE...PRICE 2/$1.00

22UH SMT INDUCTORS 5% TOL. CASE 1210..THESE ARE MOLDED TYPE ( REAL NICE )10 OF THESE AT

MOUSERS WILL COST YOU OVER $3.00...BUY 10 PIECES 22UH SMT INDUCTORS FROM DAN'S FOR $1.25

12.500 SMT CRYSTALS...CERAMIC PACKAGE..SIZE 8MM X 4.75MM..PRICE 2/$1.00

21.504 MHZ HC-49 SMT PACKAGE..PRICE 10/$1.00

8.00MHZ CRYSTALS SIZE..14MM LONG X 4.75MM WIDE..PRICE 2/$1.00

HSMS-2825 DUAL SCHOTTKY DIODES..SOT-143 PIN OUT...PRICE..10/$1.00

HSMP-3890 (BLK) PIN DIODE SOT23 PIN OUT...(ALLIED PRICE $.52 EA.) DAN'S PRICE..10 FOR $2.50

100PF CASE 1206 5% TOL NPO SMT CERAMIC CAPS....PRICE...25/$1.00

1N914 SMT DIDOES CASE SOT23..PRICE 25/$1.00

10UF 16 VOLT SMT ALUMINUM ELECTROLYTIC CAPS. 4MM CASE SIZE..PRICE 10 PIECES FOR $1.00

100UF 25 VOLT SMT ALUMINUM ELECTROLYTIC CAPS. 9MM CASE SIZE..PRICE 10/$1.00

.047MF SMT CERAMIC CAPS..CASE 0805 50 VOLT 10% TOL...PRICE..25/$1.00

---

SURFACE MOUNT TANTALUM CAPACITOR ASSORTMENT

9 DIFFERENT VAULES IN THIS ASSORTMENT

45 PIECE ASSORTMENT

5 EA. OF THE FOLLOWING

• 1UF 35 VOLT 10% TOL.CASE SIZE A 3.2MM L. X 1.6MM W. X 1.6MM H.

• 2.2UF 25 VOLT 10% TOL. CASE SIZE A 3.2MM L. X 1.6MM W. X 1.6MM H.
• 3.3UF 20 VOLT 20% TOL. CASE SIZE B 3.5MM L. X 2.8MM W. X 1.9MM H.
• 4.7UF 35 VOLT 10% TOL. CASE SIZE C 6.0MM L. X 3.2MM W. X 2.5MM H.
• 6.8UF 16 VOLT 10% TOL. CASE SIZE B 3.5MM L. X 2.8MM W. X 1.9MM H.
• 10UF 16 VOLT 10% TOL. CASE SIZE C 6.0MM L. X 3.2MM W. X 2.5MM H.
• 22UF 20 VOLT 10% TOL. CASE SIZE D 7.3MM L. X 4.3MM W. X 2.8MM H.
• 33UF 16 VOLT 20% TOL. CASE SIZE D 7.3MM L. X 4.3MM W. X 2.8MM H.
• 47UF 16 VOLT 20% TOL. CASE SIZE D 7.3MM L. X 4.3MM W. X 2.8MM H.

THIS IS A NICE LITTLE TANTALUM ASSORTMENT TO HAVE AROUND AND CLOSE TO A

$30.00 VAULE IF YOU BOUGHT FROM THE MAJOR PARTS HOUSE'S..CHECK MOUSERS

AND DIGI-KEY PRICE...THESE ARE ALL NEW..NO PULLS...DAN'S PRICE IS.......$7.50

100 ASSORTED SURFACE MOUNT TANTALUM

CAPACITORS

THIS IS A NICE ASSORTMENT OF SURFACE MOUNT TANTALUM CAPACITORS

THIS ASSORTEMENT CONTAINS VAULES FROM 1UF TO 47UF..DIFFERENT

SIZES AND VOLTAGES..AT LEAST 8 DIFFERENT VAULES..

A GREAT DEAL..CHECK OUT WHAT THESE COST AT YOUR FAVORITE MAIL

ORDER HOUSE...BAG OF 100 FOR ONLY $8.50..

---

180 PIECE COG AND NPO SURFACE MOUNT CAPACITOR

KIT.

KIT CONTAINS 37 DIFFERENT VAULES...5 EA.

OF THE FOLLOWING VAULES LISTED BELOW.

• .5PF ( 1/2PF ) +/- .25PF COG. 50 VOLT CASE 0603
• 1PF +/- .25PF COG. 50 VOLT CASE 0805
• 1.2PF +/- .25PF COG. 50 VOLT CASE 0603
• 1.8PF +/- .25PF COG. 50 VOLT CASE 0603
• 1.5PF +/- .25PF COG. 50 VOLT CASE 0805
• 2.2PF +/- .25PF COG. 50 VOLT CASE 0603
• 2.7PF +/- .25PF COG. 50 VOLT CASE 0603
• 3.0 PF +/- .25PF COG. 50 VOLT CASE 0603
• 3.3PG +/- .25PF COG. 50 VOLT CASE 0603
• 3.9PF +/- .25PF COG. 50 VOLT CASE 0603
• 4.7PF +/- .25PF COG. 50 VOLT CASE 0603
• 5PF +/- .25PF COG. 50 VOLT CASE 0603
• 6.2PF +/- .25PF COG. 50 VOLT CASE 0603
• 8.2PF +/- .25PF COG. 50 VOLT CASE 0603
• 10PF 5% NPO 50 VOLT CASE 0805
• 12PF 5% NPO 50 VOLT CASE 0603
• 15PF 5% NPO 50 VOLT CASE 0603
• 18PF 10% COG. 50 VOLT CASE 0603
• 20PF 5% NPO 50 VOLT CASE 1206
• 22PF 5% NPO 50 VOLT CASE 0603
• 27PF 5% NPO 50 VOLT CASE 0603
• 33PF 5% NPO 50 VOLT CASE 0603
• 39PF 5% NPO 50 VOLT CASE 0603
• 47PF 5% NPO 50 VOLT CASE 0603
• 56PF 5% NPO 50 VOLT CASE 0603
• 82PF 5% NPO 50 VOLT CASE 0603
• 100PF 5% NPO 50 VOLT CASE 0603
• 150PF 5% NPO 50 VOLT CASE 0603
• 220PF 5% NPO 50 VOLT CASE 0603
• 270PF 5% NPO 50 VOLT CASE 1206
• 300PF 5% NPO 50 VOLT CASE 0603
• 330PF 5% NPO 50 VOLT CASE 0805
• 390PF 5% NPO 50 VOLT CASE 0805
• 470PF 5% NPO 50 VOLT CASE 0805
• 820PF 5% NPO 50 VOLT CASE 0603
• 1000PF 5% NPO 50 VOLT CASE 0603

THIS IS A GREAT KIT OF COG. AND NPO SURFACE MOUNT CAPACITORS.

ALL ARE MARKED WITH VAULE AND PRICE ON THIS 180 PIECE SMT NPO-COG KIT IS ONLY $12.50

---

500 PLUS PIECE SURFACE MOUNT GRAB BAG.

This a good way to stock get started in surface mount technology.

lots of good parts here..there are capacitors, resisistors...semiconductors and a lot more...

may contain crystals..trim pots...inductors..etc..

PRICE IS ONE 500 PLUS PIECE BAG FOR $2.50

OR BUY 5 BAGS FOR ONLY $10.00

DAN'S CLOSE OUT SECTION

lISTED BELOW ARE SOME CLOSE OUT AND EXCESS INVENTORY..ALL ITEMS IN DAN'S CLOSE OUT SECTION ARE SOLD AS IS..AND ALL SALES ARE FINAL..WHAT THIS MEANS NO RETURNS...PLEASE MAKE SURE THAT THE ITEMS LISTED BELOW ARE ITEMS THAT YOU WANT..THERE ARE SOME GOOD DEALS HERE..

---

2.2UF 50 VOLT ELECTROLYTIC CAPS..SMALL SIZE..RADIAL LEADS..LONG LEADS..GREAT DEAL..25/$1.00

---

VERY NICE SLUG TUNNED IF CANS

HERE ARE SOME NICE TOKO SLUG TUNNED IF CANS...10MM SIZE..5 PIN BASE...RANGE ON 2 PIN SIDE IS APPROX. 32-70UH...RANGE ON 3 PIN BASE IS APPROX 190-590UH AND CENTER TAP RANGE APPROX...60-120UH..PRICE ON THESE NICE IF CANS IS..2/$1.00

WHILE THEY LAST.

---

3.065-5.953UH IF CANS

HERE ARE SOME NICE 10MM SIZE SLUG TUNNED IF CANS..GREEN CORE AND APROX INDUCTANCE RANGE IS 3.065-5.953UH..NICE TO HAVE AROUND..SPECIAL SALE DEAL..10/$3.50

---

5.6UH CHOKES 10% TOL.

5.6UH Chokes 10% tol. (green-blue-gold)long leads.

Price on these nice 5.6uh chokes is...

25/$1.00

---

1MH (1000UH ) SURFACE MOUNT INDUCTORS.

Here are some nice 1000uh ( 1MH ) surface mount inductors...case size 1812 and 5% tol.

Nice to have around and price at...

25/$2.50

Nice Face Plates

Nice face plate or end plate for home made enclosures.

Size 1-1/2" high and 3-1/2" long and the 2 holes will take 4-40 machine screws or 6-32.

Price on these nice face or end plates..

10/$1.50

---

680UH CHOKE 5% TOL. 650 MA.

Nice 680uh choke 650 ma. 5% tol. long leads..nice chokes.

Price on these nice chokes...

10/$2.50

---

10 PIECES 100 UH CHOKES 5% TOL.

THESE ARE NICE 100 UH 5% TOL. CHOKES..SPECIAL SALE PRICE..BUY 10 FOR..$2.50

---

***4 WATT QRP DUMMY LOAD***

KIT CONTAINS 2 PIECES 2 WATT 100 OHM 5% TOL. CARBON COMPOSTION RESISTORS AND 1 RCA PLUGS...JUST HOOK 2 OF THE RESISTORS IN PARRALLE..ON ONE END OF THE 2 RESISTORS HOOK TOGETHER ON THE OTHER END..ONE LEAD OF ONE RESISTOR GOES TO THE CENTER OF THE CONNECTOR..THE OTHER TO THE SHELL..AND THATS IT...SO THIS DEAL INCLUDES 2 100 OHM 5% TOL. 2 WATT CARBON COMPOSITION RESISTORS AND 1 RCA PLUGS..KIT ALSO INCLUDES ONE RCA PANEL MOUNT JACK.. PRICE..$1.00

---

500 PIECE GRAB BAGS.

500 Piece grab bags are back.

These have a little of this and a little of that in them.

like crystals, caps, resistors,inductors and other odds and ends, and have always sold out in the past.

Price on the 500 Piece grab bags $5.00

Special deal..buy 2 of the 500 piece grab bags for only...

$8.00

NOTE: Bcause of weight the 500 piece grab bags are available to USA BUYERS ONLY.

---

115 PIECE CRYSTAL DEAL

Nice 115 Piece crystal deal..These are all new and kit includes the following crystals.

10 Piece 8.000mhz....HC-18U case.

10 Pieces 4.032mhz....HC-18U case.

10 Pieces 14.318mhz....HC18-U case.

5 Pieces 3.579mhz....HC-18U case.

5 Pieces 3.6864mhz....HC-18U case.

5 Pieces 1.856mhz....HC-18U case.

10 Pieces 24.000mhz....HC-18U case.

10 Pieces 12.08391mhz....HC18-U case.

10 Pieces 18.432mhz HC-49 case.

30 Pieces 13.500mhz....HC-18U case.

10 Pieces 10.110mmz....surface mount type.

If you bend leads vertical they are long enough for thru hole insertion.

Price on this nice 115 Piece crystal assortment..

$7.00

---

15UH MOLDED CHOKES 5% TOL.

Nice 15uh 5% tol. molded inductors..{brown-green-black-gold }

What you see in photo is what you will receive.

Price on these nice 15uh chokes...

10/$2.50

Or buy 25 pieces for only...

$4.00

---

CLICK HERE FOR LOTS MORE CLOSE OUTS

AND SPECIAL DEALS

This is the end of Dan's Virtual Internet Catalog.

This On Line Catalog Will Continue to Grow

as Time Permits.

Copyright 2005, 2006,2007,2008,2009,2010,2011,2012,2013,2014,1015
